High Quality Lithium Rechargeable Battery LiFePo4 24V60Ah Battery Pack with Connector
Battery pack general description
The 24V60Ah lifepo4 battery pack is used for solar street light; FORZATEC uses 3.2V6.0Ah lifepo4 cells (AMW-LFP-6.0) to configure it (8S10P).The battery pack is protected by BMS; the BMS can help the battery pack from over-charge, over-discharge, over-temperature, over-current, short-circuit and equalizing the voltage between cells.
Features:
1.High energy density and capacity,low impedance,need less of batteries series and parallel connected
2.Excellent safety performance,no burning,no explosion,no leakage,long lifecycle
3.Excellent storage performance nd low self-discharge rate
4.Test passed such over-charge,over-discarge,over-current,short circuit,150C thermal shock and 1.2m drop.etc
5.Various mechanical dimensions,thin and light weight,thickness can be adjusted while the width and lenght keep the same
6.Clean"Green" energy,environment friendly
7.No memory effect,can be recharged anytime anywhere
Battery pack specifications
| Item | Specifications |
| Battery type | Lifepo4 |
| Nominal voltage | 25.6V |
| Nominal Capacity | ≥60Ah (Test condition @ 0.3C, 25°C) |
| Nominal charge current | 20A |
| Max charge current | 40A |
| Max continuous discharge current | 30A |
| Max pulse discharge current | 60A |
| Charge cut-off voltage | 29.2V |
| Discharge cut-off voltage | 21.6V |
| Standard charge and discharge method | CC and CV |
| Self-discharge | < 3% per month |
| Battery pack size | L148mm × W115mm × H880mm |
| Battery pack weight | 16±1kg |
| Battery packing | Aluminum box |
| Charge and discharge port | customized |
| Charge temperature range | -5 °C to 55°C |
| Discharge temperature range | 0 °C to 55°C |
| Storage temperature range | -20 °C to 55°C |
| Storage humidity | 25% to 85% |
| Charge and discharge port | customized |
| Charge and discharge wire diameter | customized |
| Charge and discharge wire length | customized |
